Model

NVR516-128

Video and AudPio

IP Video Input

128-ch

Two-way audio Input

1-ch, RCA

Network

Incoming bandwidth

512Mbps

Outgoing bandwidth

384Mbps

Remote connection

128

Video/Audio Output

HDMI/VGA Output

VGA:

1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz

HDMI1:

4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz

HDMI2:

4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz

Recording Resolution

12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Audio Output

1-ch, RCA

Synchronous Playback

16-ch

Decoding

Compression

H.265/H.264

Live view/Playback

12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF

Capability

4 x 4K@30, 16 x 1080p@30, 36 x 720p@30, 64 x D1

Hard Disk

SATA

16 SATA interfaces

Capacity

up to 8TB for each disk

miniSAS

2 miniSAS ports

Disk array

Array type

RAID1,RAID5

Number of array

8

External Interface

Network Interface

4 RJ-45 10M/100M/1000M adaptive Ethernet Interface

2 1000M SFP Ethernet Interface

Network Function

HTTP,HTTPS,UPnP, RTSP,RTP, SMTP, NTP, DHCP, DNS,IP Filter, PPPoE, DDNS, FTP, IP Server, P2P

Serial Interface

1 x RS-232, 1 x RS-485

USB Interface

Rear panel: 4 x USB3.0

Alarm In

24-ch

Alarm Out

8-ch

Decoding Card (optional)

2 slots (4 HDMI or 6 HDMI outputs per card)

Power Output

12V

General

Power Supply 1

100 ~ 240V

Power Supply 2(optional)

Redundant power supply, 100 ~ 240V

Consumption ( without HDD )

≤ 50 W

Working Temperature

-10°C ~ + 55°C ( +14°F ~ +131°F )

Working Humidity

10% ~ 90%

Chassis

19-inch rack-mounted 3U chassis

Dimensions

131mm × 482mm ×477mm ( 5.1" × 19.0" × 18.8" )

Weight ( without HDD )

≤ 10 Kg ( 22.05 lb )
